規格 Specification | |
系統 System | |
處理器 Processor | Intel® 4th Gen. Core™ i3/i5/i7, Pentium®, Celeron® processor, LGA1150 Socket |
芯片 Chipset | Intel® H81 Chipset |
內存 Memory | DDR3-1333/1600MHz, 2 x UDIMM Slot, up to 16GB |
圖形 Graphics | Intel® HD Graphics, dual display |
存儲 Storage | 2 x SATA 2.0, 1 x SATA 3.0, 1 x M.2(2242/2280) |
操作系統 OS | Windows XP (limited function)/7/8/10, Linux |
外部接口 External I/O | |
網口 Ethernet | 2 x RJ45 Intel i211AT GbE (10/100/1000 Mbps) |
顯示 Video | 1 x VGA: max resolution up to 1920 x 1200 1 x DVI-D: max resolution up to 1920 x 1200 |
音頻 Audio | 1 x Line-in, 1 x Line-out, 1 x Mic-in |
串口 COM | 2 x RS232/RS422/RS485(with auto flow control,with Power 5V/12V) |
USB | 6 x USB 2.0, 2 x USB 3.0(Support Ennoconn USB SR Pro Technology) |
PS/2 | 1 x PS/2(mini-DIN-6) |
按鈕 Button | 1 x Power Button, 1 x Reset Button |
指示燈 LED | 1 x Power LED, 1 x HDD LED |
內部接口 Internal I/O | |
擴展接口 Expansion | 1 x PCIe X 16 Slot, 2 x PCIe X 4 Slot(X 1 Link), 4 x PCI Slot |
USB | 2 x USB 2.0 (Type A + Pin header) |
GPIO | 1 x 16-bit GPIO |
串口 COM | 2 x RS232/RS485, 2 x RS232 |
風扇 FAN | 1 x CPU Fan , 2 x System Fan |
環境 Environmental | |
操作溫度 Operating Temp. | 0℃ ~ 40℃ |
存儲溫度 Storage Temp. | -20℃ ~ 60℃ |
濕度 Relative Humidity | 5% ~ 95%, 非凝結狀態 Non-condensing |
隨機振動 Random Vibration | 5~500Hz, 1Grms (HDD)operation |
正弦振動 Sin Vibration | 5~500Hz, 2G Non-operation |
機械沖擊 Shock | 10G @ 11ms operation |
電源 Power | |
電源輸入 Power Input | 100~240V(AC) |
電源功耗 Power Watt | 250W |
機構Mechanical | |
外觀 Housing | SGCC |
尺寸 Dimension | 400(L) x 426.4(W) x 88.4(H)mm |
重量 Weight | 10kg(約) |
安裝方式 Mounting | 機柜式 (Rack-Mount) |
認證Certification | |
安規認證 Safety Certification | CCC |
