| 規格 Specification | ||
| 系統 System | ||
| 處理器 Processor | Intel® 6th/7th Gen. Core™ i3/i5/i7, Pentium®, Celeron® processor, LGA1151 Socket | |
| 芯片 Chipset | Intel® Q170 Chipset | |
| 內存 Memory | DDR4-2133/2400MHz, 4 x UDIMM Slots, up to 64GB | |
| 圖形 Graphics | Intel® HD Graphics, triple display | |
| 存儲 Storage | 4 x SATA 3.0, 1 x M.2 (SATA3.0 or PCIE3.0x1) 2242/2280 | |
| 操作系統 OS | Windows 7/8/10, Linux | |
| 外部接口 External I/O | ||
| 網口 Ethernet | 1 x Intel® i219-LM GbE, 1 x Intel i211-AT (10/100/1000 Mbps) | |
| 顯示 Video | 1 x DVI-D: max resolution up to 1920 x 1200 1 x VGA: max resolution up to 1920 x 1200 1 x DP++: max resolution up to 4096 x 2160 | |
| 音頻 Audio | 1 x Line-in, 1 x Line-out, 1 x Mic-in | |
| 串口 COM | 1 x RS232/422/485(with auto flow control, with Power 5V/12V) | |
| USB | 6 x USB 3.0, 4 x USB 2.0 (Rear USB ports support Ennoconn USB SR Pro) | |
| 按鈕 Button | 1 x Power Button, 1 x Reset Button | |
| 指示燈 LED | 1 x Power LED, 1 x HDD LED | |
| 內部接口 Internal I/O | ||
| 擴展接口 Expansion | 2 x PCIe X 16 Slot (1x16 or 2x8 link), 3 x PCIe X 4 Slot (X 4 Link), 2 x PCI Slot | |
| USB | 4 x USB 2.0 (Type A + Pin header) | |
| 風扇 FAN | 1 x CPU Fan, 2 x System Fan | |
| GPIO | 1 x 16-bit GPIO | |
| 串口 COM | 1 x RS232/RS422/RS485, 2 x RS232/485, 2 x RS232 | |
| PS/2 | 1 x PS/2 pinheader (keyboard and mouse) | |
| LPT | 1 x LPT pinheader | |
| 環境 Environmental | ||
| 操作溫度 Operating Temp. | 0℃ ~ 40℃ | |
| 存儲溫度 Storage Temp. | -20℃ ~ 60℃ | |
| 濕度 Relative Humidity | 5% ~ 95%, 非凝結狀態Non-condensing | |
| 隨機振動 Random Vibration | 5~500Hz, 1Grms (HDD)operation | |
| 正弦振動 Sine Vibration | 5~500Hz, 2G Non-operation | |
| 機械沖擊 Shock | 10G@ 11ms operation | |
| 電源 Power | ||
| 電源輸入 Power Input | 100~240V(AC) | |
| 電源功耗 Power Watt | 300W | |
| 機構Mechanical | ||
| 外觀 Housing | SGCC | |
| 尺寸 Dimension | 455(L) x 427(W) x 178(H)mm | |
| 重量 Weight | 15kg(約) | |
| 安裝方式 Mounting | 機柜式 (Rack-Mount) | |
| 認證Certification | ||
| 安規認證 Safety Certification | CCC | |
